Taurus Air Rivet Tool For Standard & Structural Rivets
Brands you know and trust - Gesipa
Taurus air rivet gun, high volume production gun from Gesipa.
Professional production rivet guns from Germany. The Taurus air powered range of riveters are powerful, lightweight and virtually maintenance free. Installing standard and structural rivets with numerous features that include; fast single trigger installation, rivet suction & holding capacity, spent pintail extraction system, and a low wear jaws system that is powered by air rather than springs. See the technical tab below for the complete list of rivet sizes and other data. A hassle-free option with fewer moving parts, so less service and repairs. Clever Huh! Check out the rivet gun blog for selection information.
Taurus 3 (RT-GT3) can install standard rivets from diameter size 2.4 mm (3/32'), 3.2mm (1/8), 4.0mm (5/32), 4.8mm (3/16), 6.4mm (1/4). Plus structural rivets 4.8 mm (3/16') & 6.4mm (1/4)*.
Taurus 4 (RT-GT4) can install standard rivets diameter size 4.8mm (3/16), 6.4mm (1/4), Plus structural rivets diameter size 4.8mm (3/16), 6.4mm (1/4), 7.9mm (5/16)*.
Taurus air rivet gun features.
- High quality production rivet gun. Made in German.
- Rivet vacuum and holding capacity + pintail extraction system.
- Fast single trigger installations with an impressive setting force.
- Virtually maintenance free with fewer moving parts.
- Compact & lightweight and so much more.
Taurus® air rivet gun, high volume production guns from Gesipa®.
Professional production rivet guns from Germany. The Taurus® air powered range of riveters are powerful, lightweight and virtually maintenance free. Installing standard and structural rivets with numerous features; fast single trigger installation, rivet suction & holding capacity, spent pintail extraction system, and a low wear jaws system that is powered by air rather than springs. A hassle-free option with fewer moving parts, so less wear and tear. Clever Huh!
A key feature of this guns is the rivet vacuum & holding capacity, this means the gun vacuums up the rivet and holds it in place as you align it with the hole and automatically extract the waste pin to the collection bottle after installation (you don't have to tilt the gun to push through the waste pin).
Taurus® air rivet gun features.
- High quality production rivet gun. Made in German.
- Rivet vacuum and holding capacity + pintail extraction system.
- Fast single trigger installations with an impressive setting force.
- Virtually maintenance free with fewer moving parts.
- Compact & lightweight and so much more.
Taurus 3 (RT-GT3) can install standard rivets from diameter size 2.4 mm (3/32'), 3.2mm (1/8), 4.0mm (5/32), 4.8mm (3/16), 6.4mm (1/4). Plus structural rivets 4.8 mm (3/16') & 6.4mm (1/4)*
| RIVET GUN INSTALLATION GUIDE RT-GT3 or T3 |
RIVET DIAMETER | ||||||||||
| STANDARD RIVETS | STRUCTURAL RIVETS | ||||||||||
| 2.4 | 3.2 | 4.0 | 4.8 | 6.4 | 4.8 | 6.4 | 7.9 | 9.5 | |||
| Aluminium | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |||||
| Steel | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |||||
| Stainless-Steel* | ✓ | ✓ | ✓ | ✓ | ✓ | ||||||
Taurus 4 (RT-GT4) can install standard & structural rivets diameter size 4.8mm (3/16), 6.4mm (1/4), 7.9mm (5/16)*.
| RIVET GUN INSTALLATION GUIDE RT-GT4 or T4 |
RIVET DIAMETER | ||||||||||
| STANDARD RIVETS | STRUCTURAL RIVETS | ||||||||||
| 2.4 | 3.2 | 4.0 | 4.8 | 6.4 | 4.8 | 6.4 | 7.9 | 9.5 | |||
| Aluminium* | ✓ | ✓ | ✓ | ✓ | ✓ | ||||||
| Steel | ✓ | ✓ | ✓ | ✓ | |||||||
| Stainless-Steel | ✓ | ✓ | ✓ | ✓ | |||||||
Rivet Tool Taurus 3. Pressure; 5-7 bar (72-101 psi). Pulling force 14.0kN. Stroke 25mm. Dimensions (L X H) 312 X 317mm. Weight 1.9kg. Rivet tool comes with; nose tips for rivet diameter. 2.4 mm - 6.4 mm, wrench X 2, oil bottle, one refill oil container, manual and spare parts list.
Rivet Tool Taurus 4. Pressure; 5-7 bar (72-101 psi). Pulling force 20.0 kN. Stroke 19 mm. Weight 2.0 kg. Dimensions (L X H) 312 X 332mm. Rivet tool comes with; nose tips for 4.8 mm (3/16'), 6.4 mm (1/4') & 7.9 mm (5/16'). Wrench X 2, oil bottle, one refill oil container, manual and spare parts list.
Taurus® air rivet gun, high volume production guns from Gesipa®.
Professional production rivet guns from Germany. The Taurus® air powered range of riveters are powerful, lightweight and virtually maintenance free. Installing standard and structural rivets with numerous features; fast single trigger installation, rivet suction & holding capacity, spent pintail extraction system, and a low wear jaws system that is powered by air rather than springs. A hassle-free option with fewer moving parts, so less wear and tear. Clever Huh!
A key feature of this guns is the rivet vacuum & holding capacity, this means the gun vacuums up the rivet and holds it in place as you align it with the hole and automatically extract the waste pin to the collection bottle after installation (you don't have to tilt the gun to push through the waste pin).
Taurus® air rivet gun features.
- High quality production rivet gun. Made in German.
- Rivet vacuum and holding capacity + pintail extraction system.
- Fast single trigger installations with an impressive setting force.
- Virtually maintenance free with fewer moving parts.
- Compact & lightweight and so much more.
Taurus 3 (RT-GT3) can install standard rivets from diameter size 2.4 mm (3/32'), 3.2mm (1/8), 4.0mm (5/32), 4.8mm (3/16), 6.4mm (1/4). Plus structural rivets 4.8 mm (3/16') & 6.4mm (1/4)*
| RIVET GUN INSTALLATION GUIDE RT-GT3 or T3 |
RIVET DIAMETER | ||||||||||
| STANDARD RIVETS | STRUCTURAL RIVETS | ||||||||||
| 2.4 | 3.2 | 4.0 | 4.8 | 6.4 | 4.8 | 6.4 | 7.9 | 9.5 | |||
| Aluminium | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |||||
| Steel | ✓ | ✓ | ✓ | ✓ | ✓ | ✓ | |||||
| Stainless-Steel* | ✓ | ✓ | ✓ | ✓ | ✓ | ||||||
Taurus 4 (RT-GT4) can install standard & structural rivets diameter size 4.8mm (3/16), 6.4mm (1/4), 7.9mm (5/16)*.
| RIVET GUN INSTALLATION GUIDE RT-GT4 or T4 |
RIVET DIAMETER | ||||||||||
| STANDARD RIVETS | STRUCTURAL RIVETS | ||||||||||
| 2.4 | 3.2 | 4.0 | 4.8 | 6.4 | 4.8 | 6.4 | 7.9 | 9.5 | |||
| Aluminium* | ✓ | ✓ | ✓ | ✓ | ✓ | ||||||
| Steel | ✓ | ✓ | ✓ | ✓ | |||||||
| Stainless-Steel | ✓ | ✓ | ✓ | ✓ | |||||||
Rivet Tool Taurus 3. Pressure; 5-7 bar (72-101 psi). Pulling force 14.0kN. Stroke 25mm. Dimensions (L X H) 312 X 317mm. Weight 1.9kg. Rivet tool comes with; nose tips for rivet diameter. 2.4 mm - 6.4 mm, wrench X 2, oil bottle, one refill oil container, manual and spare parts list.
Rivet Tool Taurus 4. Pressure; 5-7 bar (72-101 psi). Pulling force 20.0 kN. Stroke 19 mm. Weight 2.0 kg. Dimensions (L X H) 312 X 332mm. Rivet tool comes with; nose tips for 4.8 mm (3/16'), 6.4 mm (1/4') & 7.9 mm (5/16'). Wrench X 2, oil bottle, one refill oil container, manual and spare parts list.
